Dual Side-access Fiber Optic Test Fixture

Side-access Fiber Optic Test Fixture

This custom Fiber-optic Test Fixture simultaneously engages connectors in both sides of the UUT.  The fiber optic device is placed into the middle of the test fixture.  When the fixture’s gate is closed, a pneumatic cam moves two blocks of test connectors into the device under test, one from each side.
